24 Hour RF Programmable Room Temperature Adjustable Thermostat
Product Description
Type :Underfloor Heating /Air Conditioning Thermostat
Function : Indoor Floor heating system Temperature Control
Feature : Multi-function and easy operation
Power Voltage :24 V AC / DC,...250 V AC; 50 Hz
Load Current : 6(2)A, 230V
Detection Temp. Range : 0-40℃
Set Temp. Range : 5-35℃
Control Temp. Range : 5-35℃
Accuracy : ±0.5℃
Certification : CE
Material : Anti-flammable PC +ABS
| Power Supply | 230VAC, 50HZ(Receiver) |
| Setpoint Range | 5~35℃ |
| Setting Unit | 0.5℃ / step |
| Display | LCD display |
| Mode Setting | Heating, Cooling and Ventilating |
| Fan Speed Adjust | High, Medium, Low and Automatic fan speed control |
| Cycling Fan Control | Fan cycled running with thermostat |
| Control Performance | ON/OFF control |
| Differential | 1℃ |
| Thermostat Output | relay |
| Switch current rating | 6 A (2 A inductive load) |
| Temperature Sensor | NTC |
| Enclosure | Fire retardant PC ABS |
| Minimum Operational Life | Thermostat contacts: 100,000 cycles |
| Backlight Function(optional) | Blue light |
| Dimensions | 120 x77 x28 mm |
| Hole Pitch | 60 mm |
| Environmental requirements | Operating temperature range 0 ~ 40℃, Humidity range 5 ~ 95%RH (non-condensing) |
| Electrical box size | 62×46×24.5mm(Normal); 48×48×25mm(European standard) |
More Detailed Photo
Product Uses
FAQ
1.Are you manufacturer or trading company?
We are professional thermostats manufacturer founded in 2012,
located in Dongguan city, Guangdong Province, China. Welcome to
visit our factory!
2.Can I place a sample order first?
Yes, you can place sample order to check the quality and testing
it. Delivery cost is on buyer's account.
3.What is your delivery time?
Normally within 7~15 days, mass order should be negotiated.
4.What's the payment term?
T/T, L/C, Western Union, Paypal, Alibaba secure payment, D/P.
5.Can you do OEM and ODM for us?
Yes, we are professional in providing OEM and ODM service. We
support both standard and customized products, we can put your logo
on the products. Our experienced R&D team will support
technical questions.
6.How to control quality?
1. All the raw materials by ICQ(Incoming quality control).
2. IPQC(In Processing Quality control).
3. QC fully inspection before packing.
4. Before shipment, do fully inspection again.
